Submersible Sewage Pump

Submersible Sewage Pump

Range:

• Maximum flow: 8000 m3/ hr
• Maximum head: 100 m
• Temperature: up to 60°C

Product Design Features:

• Vertical submersible sewage pumps
• Stage: Single
• Non clog (free flow / single / multi-channel) impeller
• Large free passage up to 200mm
• Double mechanical seal
• Oil barrier chamber with float switch winding / bearing temperature indicators / moisture sensor

Optional features:

• Stationary / portable installation
• Dry / wet pit installation
• With / without macerator
• Mixer head for agitation
• With / without ceram coating for aggressive liquid

Material of Construction:

• Casing: Cast iron / Engineering plastic
• Impeller: Cast Iron / SS / Engineering Plastic
• Other materials on request

Application:

• Municipal raw sewage transfer
• Sewage treatment plants
• Effluent treatment plants
• Dirty water in industry

Prime Movers:

• Submersible electric motors with IP68 protection variety of motors include oil cooled, media cooled motors, flameproof motors
